EXD-GW100 Modular Automation Gateway
Industrial-grade edge controller and protocol converter for distributed I/O systems. Supports secure data acquisition, local logging, and robust cloud telemetry.
RENDER::EXD-GW100
Industrial Features
2x RS485 (Modbus RTU Master) interfaces
Ethernet 10/100 (Modbus TCP) connectivity
Industrial MQTT (TLS 1.2+) telemetry
30-day onboard data buffering
Device heartbeat monitoring and alarm logging
Secure encrypted Over-The-Air (FOTA) updates
Optional LTE Cat-1 cellular variant
Technical Specifications
| supply Voltage | 24VDC (18–30VDC) with reverse polarity protection |
|---|---|
| power Consumption | <6W |
| interfaces | 2x RS485, 1x Ethernet 10/100, 1x USB Host |
| wireless | Optional Wi-Fi / LTE Cat-1 cellular connection |
| isolation | 3kVrms RS485 Isolation |
| data Buffering | 30-Day onboard non-volatile memory |
| security | Role-Based authentication, SSL/TLS 1.2+ encryption |
| operating Temp | -25°C to +70°C |
| enclosure | DIN Rail Mount (TS35), 72mm Width, IP20 |
Telemetry Architecture
Supported Protocols
Modbus RTUModbus TCPMQTT TLSHTTPS
Target Applications
- Distributed I/O telemetry
- Protocol conversion (Modbus to MQTT)
- Remote asset monitoring
- Industrial edge computing
